Features
1. The payload of this space cab truck is 1.5 ton.
2. This cargo truck adopts 2596cc turbocharged diesel engine, which can satisfy the Euro 1 and Euro 2 emission standards.
3. Curb weight of this light truck is 2515 kg.
4. Our Pluto 1.5 ton space cab trucks are equipped with 5-speed manual gearbox.
5. Gross vehicle weight can reach 4210 kg.
6. This cargo truck can be configured with vertical in-line, 4-cylinder diesel engine.
7. 1.5 ton space cab truck is manufactured with newly-designed modern cabin (1780 mm in width) which can be tilted by 45 degrees for convenient daily maintenance.
LANTYPC Vehicle Vehicle Co., Ltd. is a professional space cab truck manufacturer and supplier in China. We have mini truck, mini bus and pickup truck as well as light truck for sale. With rich marketing and management experience, our cargo trucks are marketable in overseas markets. Till now, we have exported our space cab trucks to USA, Guatemala, Bahamas, Costa Rica, Ecuador, Venezuela, Colombia, Saint Martin, Bolivia, Malta, Namibia, Sudan, French Polynesia, Poland, Singapore, Yugoslavia and Botswana.
Specification Space Cab Truck Dimension
| Model |
BJ1040PPS4 |
| Driving type |
LHD |
| Overall length (mm) |
5985 |
| Overall width (mm) |
1950 |
| Overall height (mm) |
2200 |
| Wheelbase (mm) |
3200 |
| Tread, front/rear (mm) |
1460/1470 |
| Ground clearance (mm) |
180 |
| Curb vehicle weight (kg) |
1705 |
| Gross vehicle weight (kg) |
3335 |
| Payload (kg) |
1500 |
| Max. vehicle speed (km/h) |
≥90 |
| Cargo body (inside) (mm) |
Length |
3880 |
| Width |
1860 |
| Height |
400 |
| Cabin width (mm) |
1780 |
Engine of Space Cab Truck
| Model |
BJ1040P1S4 |
| Engine model |
4D26 |
| Type |
Vertical in-line, 4-cylinder,diesel |
| Intercooler |
With |
| Bore & stroke (mm) |
90x102 |
| Displacement (cc) |
2596 |
| Compression ratio |
18:1 |
| Max. power(kw/rpm) |
47/3200(EURO I), 55/3300(EURO II) |
| Emission |
Euro I / EURO II |
| Fuel tank capacity (L) |
80 |
Drive train of Light Truck
| Model |
BJ1040PPS4 |
| Clutch |
Hydraulic, single plate, dry type diaphragm spring |
| Gearbox Type |
5 speed manual |
| Gearbox Model |
QLD5-20 |
| Max. gradeability (%) |
30 |
Chassis of Space Cab Truck
| Model |
BJ1040PPS4 |
| Frame |
Ladder shaped,']' section |
| Suspension, front/rear |
Leaf springs |
| Shock absorber, front/rear |
Double action shock absorbers |
| Axle model, front/rear |
BJ1041 |
| Steering |
Recirculating-ball |
| Brake Type |
hydraulic brake |
| Brake Front/rear |
Drums |
| Min. turning radius (m) |
6.25 |
| Tires |
6.50-16LT |
