The Pluto B6 mini vans offer standard roof, semi-high and high roof for clients to select. The seating capacity of this mini coach is from nine to fifteen persons. CD player, USB port and two speakers, front AC as well as heater are mounted on this 15-seater mini bus.
The mini van employs sensible loading proportioning valve of brake system and rear high-mount stop lamp in order to ensure safety. Our mini coaches offer water-cooled gasoline engine, turbocharged engine and direct injection diesel engine for option.

We are one of the authorized exporters of many mini van manufacturing enterprises. Our main scope of business includes mini coach export and production. As a specialized 15-seater mini bus manufacturer and supplier in China, we also provide 7-8 seats micro buses, 16-19 seats light bus, 23-32 seats light duty bus, 0.8 ton mini truck, 1.5-2.5 ton single cab truck and space cab truck, 3-8 ton light truck, 4WD truck, pickup tuck and special vehicles. LANTYPC Vehicle has become a leading and professional mini van export company depending on the aggressive marketing, innovative product design, strict quality control and excellent after-sales service.

PLUTOB6 11-14 Seats Minibus

PLUTO B6 11-14 seats minibuses were developed on the basis of high-quality chassis and body technology in the past 9 years. Compared with other similar competitors the minibuses are with more reliable chassis and comfortable seating, more options and competitive prices.

Engine

SPECIFICATIONS - Bus
	Engine equipped
Model	XG-490Q-ME	BJ6490XBD1	BJ6490XBD2	BJ6490XBD3	BJ6520XBD1	BJ6520XBD2	BJ6520XBD3
	YC4F90-23	BJ6490XBT1	BJ6490XBT2	BJ6490XBT3	BJ6520XBT1	BJ6520XBT2	BJ6520XBT3
	4JB1	BJ6490XBT1	BJ6490XBT2	BJ6490XBT3	BJ6520XBT1	BJ6520XBT2	BJ6520XBT3
Wheel base type		Short			Long
Roof type		Standard	Semi-high	High	Standard	Semi-high	High
DIMENSION & WEIGH
Overall dimension (mm)	Length	4960			5260
	Width	1700
	Height	1970	2066	2260	1970	2066	2260
Wheel base	(mm)	2590			2890
Tread, front/ rear	(mm)	1450/1430
Min. ground clearance	(mm)	165
Curb vehicle weight	(kg)	1700	1730	1760	1785	1885	1985
Gross vehicle weight	(kg)	2700	2700	2700	2910	2910	2910
Seating capacity	(persons)	11			14
Fuel tank  capacity	(L)	70
Tires		205/70R14
ENGINE (for all model)
Model		XG491Q-ME		YC4F90-23		JE493Q1
Fuel type		Gasoline		Diesel
Type		4-cylinder,  EFI, gasoline		4-cylinder,  direct injection, turbocharged, intercooled with EGR		4-cylinder, direct injection, diesel (ISUZU 4JB1 technology)
Piston displacement	(cc)	2237		2488		2771
Compression ratio		8.8:1		17.5:1		17.4:1
Max. Power	(hp/rpm)	103/4600		88/3400		78/3600
Max. torque	(N.m/rpm)	193/2000		215/2200		174/2000
Fuel consumption	(L/100km)	9.8		7.9		-
Emission		Euro II		Euro II		Euro  I
SYSTEM
Steering system		Circulating-ball-type
Suspension	Front	Independent suspension by double beams with torsion bar spring
	Rear	Leaf springs
Braking system		Hydraulic braking system with vacuum booster      Front: disc type        Rear: drum type
Gearbox		5 speed manual
Max. gradability	(%)	30

SPECIFICATIONS - Cargo Van
	Engine equipped
Model	XG-490Q-ME	BJ5030XXY61		BJ5030XXY62		BJ5030XXY64		BJ5030XXY613
	YC4F90-23	BJ5030XXY65		BJ5030XXY66		BJ5030XXY68		BJ5030XXY613
	4JB1	BJ5030XXY65		BJ5030XXY66		BJ5030XXY68		BJ5030XXY613
Wheel base type		Short				Long
Roof type		Standard		Semi-high		Semi-high		High
DIMENSION & WEIGH
Overall dimension (mm)	Length	4960				5260
	Width	1700
	Height	1970		2066				2260
Wheel base	(mm)	2590				2890
Tread, front/ rear	(mm)	1450/1430
Min. ground clearance	(mm)	165
Curb vehicle weight	(kg)	1700		1730		1885		1985
Gross vehicle weight	(kg)	2700		2700		2910		2910
Seating capacity	(persons)	2
Payload	(kg)	600
Fuel tank  capacity	(L)	70
Tires		205/70R14
ENGINE (for all model)
Model		XG491Q-ME		YC4F90-23		JE493Q1		JE493ZQ4A
Fuel type		Gasoline		Diesel
Type		4-cylinder, EFI, gasoline		4-cylinder, direct injection, turbocharged, intercooler with EGR		4-cylinder, direct injection, diesel (ISUZU 4JB1 technology)		4-cylinder, direct injection, turbocharged, diesel (ISUZU 4JB1T technology)
Piston displacement	(cc)	2237		2488		2771		2771
Compression ratio		8.8:1		17.5:1		17.4:1		17.4:1
Max. Power	(hp/rpm)	103/4600		88/3400		78/3600		84/3600
Max. torque	(N.m/rpm)	193/2000		215/2200		174/2000		-
Fuel consumption	(L/100km)	9.8		7.9		-		-
Emission		Euro II		Euro II		Euro  I		Euro II
SYSTEM
Steering system		Circulating-ball-type
Suspension	Front	Independent suspension by double beams with torsion bar spring
	Rear	Leaf springs
Braking system		Hydraulic braking system with vacuum booster      Front: disc type        Rear: drum type
Gearbox		5 speed manual

FEATURES
				Bus	Cargo van
A/C & Audio	CD Player, USB port & 2 speakers			■	■
	4 speakers			□	□
	Front AC & heater			■	■
	Rear A/C			□	□
	Rear A/C with side extended vents			□	□
Exterior	Metallic paint			□	□
	Two-tone exterior color (metallic paint)			□	□
	Steel wheels			■	■
	Wheel disc plastic covers (4 pieces)			□	□
	Aluminum wheels			□	□
	195R15 tires			□	□
	Body side molding			□	□
	Heated rear windshield glass			□	□
	Rear washer, wiper & mirror (see price list for details)			□	□
	2012 new front face			□	□
	Rear luxury lamps			□	□
	Manual outside mirrors			■	■
	Manual outside mirrors with blinkers lump			□	□
	Power outside mirrors with blinkers lump			□	□
Interior	Plastic-type flooring with wooden base			■	■
	Digital clock			□	□
	Grey inner trimming color			■	■
	Beige interior trimming color			□	□
	Wooden-grain-trim interior trim			□	□
Safety	Sensible loading proportioning valve of brake system			■	■
	Power door lock			□	□
	Backup radar			□	□
	Rear high-mount stop lamp			■	■
Mechanical	Power steering			■	■
	Tilt steering wheel			■	■
	Power front windows			□	□
Note: ■= Standard               □= Optional
