The single cab pickups can be regarded as response vehicles for fire chiefs and also for fighting brush fires. Theses pickup trucks will be fitted with emergency lights and sirens, a water tank, a gasoline-powered pump and a hose reel.
The regular cab pickup is equipped with mature high-tech auto components depending on the first grade global auto components purchasing system. Our single cab pickups have selected and used necessary accessories made by world famous brands such as TOYOTA and NISSAN. The quality of the regular cab pickup keeps in step with the trend of world development.
The single cab pickups are manufactured with the newest technologies and designing theories, together with TUNDRA and NISSAN FRONTIER, they all belong to the fifth generation of pickup truck models.
LANTYPC Vehicle has become a leading and professional pickup truck exporter depending on the aggressive marketing, innovative product design, strict quality control and excellent after-sales service. In addition to single cab pickup, we also offer double cab pickup, mid-size pickup, mini truck, light truck, single cab truck, space cab truck, micro bus, mini bus, SUV and special vehicles. We are the first company to transport three regular cab pickup trucks in one container in China.
Specification of Single Cab Pickup Dimension
| Fuel Type |
Gasoline |
Diesel |
| Cabin type |
Single Cab |
Single Cab |
| Model |
BQ1023RDY2V |
BQ1023DN8V |
| Driving type |
2WD |
2WD |
| Overall length (mm) |
5080 |
5080 |
| Overall width of regular cab pickup (mm) |
1750 |
1750 |
| Overall height (mm) |
1710 |
1710 |
| Wheelbase (mm) |
2900 |
2900 |
| Tread, front/rear (mm) |
840/1340 |
840/1340 |
| Cargo body inside (mm) |
2180x1505x480 |
| Ground clearance (mm) |
≥191 |
≥191 |
| Approach/ departure angle (º) |
≥32/≥17 |
≥32/≥17 |
| Curb weight of pickup truck |
1445 |
1445 |
| Gross vehicle weight |
2325 |
2325 |
| Seating capacity (persons) |
2 |
2 |
| Fuel tank capacity (L) |
60 |
60 |
Engine of Single Cab Pickup
| Model |
BQ1023RDY2V |
BQ1023DN8V |
| Engine model |
XG491Q-ME |
4JB1T |
| Type |
Gasoline, 4-cylinder, 4-stroke, direct fuel injection, separated sequence MFI |
Diesel, 4-cylinder, 4-stroke, turbo--charge, inter-cooler, direct fuel injection |
| Technology source |
Toyota |
ISUZU |
| Displacement (cc) |
2237 |
2771 |
| Max. power of pickup truck (hp/rpm) |
76/4200-4600 |
75/3600 |
| Max. torque (N-m/rpm) |
193/2000~2600 |
235/2000 |
| Fuel consumption (L/100KM) |
≤11.5 |
≤7.5 |
| Emission |
Euro 2 |
Euro 3 |
System of Single Cab Pickup
| Gearbox |
5 speed manual, floor shift |
| Steering |
Circulating-ball, power-assisted |
| Suspension front |
Dual arms with torsion bar springs independent suspension, with telescopic shock absorbers |
| Suspension rear |
Variable rate asymmetric leaf springs |
| Braking front / rear |
Ventilated disc/ Leading & trailing drums |
| Clutch |
Single plate, dry type diaphragm spring with tensional vibration damper |
| Min. turning radius (m) |
≤12.5 |
| Tires |
215/75R15 |
